Daewoo DRV-6815 User Manual

20
The DVD Recorder + VCR Setup menu includes six
categories, including: Installation, Recording Options,
Languages, Preference, System Info and Disc
Options. Press [SETUP] and [
…†] on the remote
control unit to view the first and second levels of the
Setup menu.
Setup Menu Overview
Setup menu
Setup menu
1 Press [SETUP]. The Setup menu appears.
2 Use […†] to select the desired category.
3 While the desired category is selected, press [√]
to move to the second level.
4 Press [ENTER] to move to the third level.
5 Use […†] to select the desired setting, then
press [ENTER] to confirm your selection.
Some items require additional steps. Press
[MENU] at any time to return to the previous
menu.
6 Press [SETUP] to exit the Setup menu.
Menu Navigation
Manual Set
To complete the set-up of your DVD Recorder + VCR
when the auto set has not stored all of the channels or
when you wish to store a new channel.
1 Press [SETUP]. The Setup menu appears.
2 Use […†] to select ‘Installation’ and press
[ENTER] to confirm.
3 While ‘Installation’ is selected, press […†] to
select ‘Manual Set’.
4 Press [ENTER]. The ‘Manual Set’ menu appears.
5 Use […†] to select ‘Standard’.
6 Use [œ√] to select the desired ‘Standard’ (PAL-
BG, PAL-II, PAL-DK, or SECAM-L).
7 Use […†] to select ‘Reception’.
8 Use [œ√] to select the desired broadcast system
(Antenna or Cable).
Antenna: If you are using a standard antenna to
receive channels.
Cable TV: If you are using basic cable to receive
channels.
9 Use […†] to select ‘Auto Search’.
10 Search the real channel number by pressing [œ
√
].
11 Select ‘Fine Tune’. You can adjust the fine tuning.
INSTALLATION Settings
Installation
Confirm Back Exit
ENTER MENU SETUP
†
†
†
Manual Set
Auto Set
Clock Setting
Adjust Channels
Installation > Manual Set
Confirm Back Exit
ENTER MENU SETUP
Standard PAL-BG
Reception Antenna
Auto Search 2
Fine Tune 0
Decoder OFF
Store Channel PR-1
Program Name - - - -
†
†
This set is equipped with the Multi-Tuner. You can
search broadcasting of other countries. If the set
can not search the channels, please Re-Install. (see
page 19.)
Installation > Manual Set
Confirm Back Exit
ENTER MENU SETUP
Standard PAL-BG
Reception Antenna
Auto Search 2
Fine Tune 0
Decoder OFF
Store Channel PR-1
Program Name - - - -
†
†
Installation > Manual Set
Confirm Back Exit
ENTER MENU SETUP
Standard PAL-BG
Reception Antenna
Auto Search 2
Fine Tune 0
Decoder OFF
Store Channel PR-1
Program Name - - - -
†
†
DF-H7DD3D-FB-I(GB) 2007.7.25 2:53 PM ˘ ` 20 mac001 1200DPI 100LPI

Daewoo DRV-6815 Specifications

Operating Environment

operating temperature	5°C to 35°C
operating humidity	5% to 90%

Power

power requirements	200–240V~, 50/60 Hz
power consumption (operation)	Maximum 26W
power consumption (standby)	5W

Recording

recordable time (DVD)	1 hour (HQ mode), 2 hours (SP mode), 4 hours (EP mode), 8 hours (SEP mode)
recordable time (VCR)	SP: 3 Hours (E-180), LP : 6 Hours (E-180)
video recording format compression	MPEG 2

VCR Specifications

tape speed SP	23.39 mm/sec
tape width	12.7 mm
rewind time	less than 150 sec (E-180)

DVD Specifications

laser wavelength	650 nm
frequency response (DVD)	8 Hz to 22 kHz
resolution	Over 500 lines (HQ Recording)

Inputs

antenna input	75 Ω
video input	1.0 Vp-p 75 Ω, sync negative, RCA jack x 2
audio input	-8.8 dBm more than 47 k, RCA jack (L, R) x 2

Outputs

video output (composite)	1.0 Vp-p, unbalanced
component video output (progressive scan)	(Y) 1.0 V (p-p), 75 Ω, negative sync, RCA jack x 1
audio output (digital)	0.5 V (p-p), 75 Ω, RCA jack x 1

Weight and Dimensions

dimensions	430 92 312 (w h d)
mass	4.96 kg
