Daewoo DTF-2950-100D - Page 84

CP-850/F Service Manual
84
Europe R&D
LOC PART CODE PART NAME DESCRIPTION REMARK
LOC PART CODE PART NAME DESCRIPTION REMARK
J63 85801060GY WIRE COPPER 1/0.6 TIN COATING
L105 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L153 5CPZ120K02 COIL PEAKING 12UH 3.5MM K (LAL02TB)
L402 85801060GY WIRE COPPER 1/0.6 TIN COATING
L501 5CPZ479K04 COIL PEAKING 4.7UH 10.5MM K (LAL04TB)
L502 5CPZ479K04 COIL PEAKING 4.7UH 10.5MM K (LAL04TB)
L506 5CPZ479K04 COIL PEAKING 4.7UH 10.5MM K (LAL04TB)
L507 5CPZ100K04 COIL PEAKING 10UH 10.5MM K (LAL04TB)
L524 5CPZ100K02 COIL PEAKING 10UH 3.5MM K (LAL02TB)
L551 5CPZ479K04 COIL PEAKING 4.7UH 10.5MM K (LAL04TB)
L568 5CPZ100K02 COIL PEAKING 10UH 3.5MM K (LAL02TB)
L601 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L602 5CPZ100K02 COIL PEAKING 10UH 3.5MM K (LAL02TB)
L603 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L605 5CPZ479K02 COIL PEAKING 4.7UH 3.5MM K (LAL02TB)
L650 5MC0000100 COIL BEAD MD-5 (HC-3550)
L709 5CPZ100K02 COIL PEAKING 10UH 3.5MM K (LAL02TB)
L711 5CPZ100K02 COIL PEAKING 10UH 3.5MM K (LAL02TB)
L713 5CPZ100K02 COIL PEAKING 10UH 3.5MM K (LAL02TB)
L730 5CPZ100K02 COIL PEAKING 10UH 3.5MM K (LAL02TB)
L737 5CPZ100K02 COIL PEAKING 10UH 3.5MM K (LAL02TB)
L742 5CPZ100K02 COIL PEAKING 10UH 3.5MM K (LAL02TB)
L744 5CPZ100K02 COIL PEAKING 10UH 3.5MM K (LAL02TB)
L801 5MC0000100 COIL BEAD MD-5 (HC-3550)
R103 RD-AZ123J- R CARBON FILM 1/6 12K OHM J
R110 RN-4Z1502F R METAL FILM 1/4 15K OHM F
R150 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R152 RD-AZ271J- R CARBON FILM 1/6 270 OHM J
R153 RD-AZ470J- R CARBON FILM 1/6 47 OHM J
R154 RD-AZ470J- R CARBON FILM 1/6 47 OHM J
R155 RD-AZ751J- R CARBON FILM 1/6 750 OHM J
R161 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R162 RD-AZ153J- R CARBON FILM 1/6 15K OHM J
R163 RD-AZ752J- R CARBON FILM 1/6 7.5K OHM J
R177 RD-AZ562J- R CARBON FILM 1/6 5.6K OHM J
R301 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J
R310 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R311 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R333 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R334 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R340 85801060GY WIRE COPPER 1/0.6 TIN COATING
R341 85801060GY WIRE COPPER 1/0.6 TIN COATING
R345 RD-4Z473J- R CARBON FILM 1/4 47K OHM J
R350 RN-AZ2201F R METAL FILM 1/6 2.2K OHM F
R351 RN-AZ2201F R METAL FILM 1/6 2.2K OHM F
R370 RD-4Z159J- R CARBON FILM 1/4 1.5 OHM J
R394 RD-AZ272J- R CARBON FILM 1/6 2.7K OHM J
R395 RD-4Z754J- R CARBON FILM 1/4 750K OHM J
R396 RD-AZ272J- R CARBON FILM 1/6 2.7K OHM J
R397 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
R414 RD-AZ681J- R CARBON FILM 1/6 680 OHM J
R420 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R424 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J
R430 RD-4Z103J- R CARBON FILM 1/4 10K OHM J
R440 RD-4Z274J- R CARBON FILM 1/4 270K OHM J
R501 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R502 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R504 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R507 RD-AZ562J- R CARBON FILM 1/6 5.6K OHM J
R510 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R511 RD-AZ330J- R CARBON FILM 1/6 33 OHM J
R512 RD-AZ330J- R CARBON FILM 1/6 33 OHM J
R513 RD-AZ330J- R CARBON FILM 1/6 33 OHM J
R514 RD-AZ151J- R CARBON FILM 1/6 150 OHM J
R515 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
R516 RD-AZ752J- R CARBON FILM 1/6 7.5K OHM J
R517 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R518 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R519 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R520 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R524 RD-AZ391J- R CARBON FILM 1/6 390 OHM J
R525 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R533 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
R534 RD-AZ391J- R CARBON FILM 1/6 390 OHM J
R535 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R537 RD-AZ301J- R CARBON FILM 1/6 300 OHM J
R538 RD-AZ301J- R CARBON FILM 1/6 300 OHM J
R540 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R545 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R550 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R551 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R563 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R564 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R566 RD-AZ220J- R CARBON FILM 1/6 22 OHM J
R570 RD-AZ271J- R CARBON FILM 1/6 270 OHM J
R576 RD-AZ151J- R CARBON FILM 1/6 150 OHM J
R580 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R588 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R590 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R593 RD-AZ203J- R CARBON FILM 1/6 20K OHM J
R594 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R595 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R599 RD-AZ151J- R CARBON FILM 1/6 150 OHM J
R602 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
R605 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R606 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R610 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
R612 RD-AZ474J- R CARBON FILM 1/6 470K OHM J
R613 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R614 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R615 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R616 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R620 RD-AZ242J- R CARBON FILM 1/6 2.4K OHM J
R621 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R622 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R641 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R642 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R646 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R647 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R649 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R650 RD-AZ362J- R CARBON FILM 1/6 3.6K OHM J
R651 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R652 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R660 RD-AZ362J- R CARBON FILM 1/6 3.6K OHM J
R680 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R700 RD-2Z332J- R CARBON FILM 1/2 3.3K OHM J
R701 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R702 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R703 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R704 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R709 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R720 RD-AZ681J- R CARBON FILM 1/6 680 OHM J
R741 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R748 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R777 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
R781 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R788 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R789 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R790 RD-AZ512J- R CARBON FILM 1/6 5.1K OHM J
R804 RD-4Z479J- R CARBON FILM 1/4 4.7 OHM J
R805 RD-2Z104J- R CARBON FILM 1/2 100K OHM J
R807 RD-4Z221J- R CARBON FILM 1/4 220 OHM J
R808 RD-4Z182J- R CARBON FILM 1/4 1.8K OHM J
R809 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R810 RD-4Z220J- R CARBON FILM 1/4 22 OHM J
