LOC PART CODE PART NAME DESCRIPTION REMARK
R811 RC-2Z565KP R CARBON COMP 1/2 5.6M OHM K
R817 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R818 RD-AZ683J- R CARBON FILM 1/6 68K OHM J
R820 RD-4Z363J- R CARBON FILM 1/4 36K OHM J
R821 RD-AZ563J- R CARBON FILM 1/6 56K OHM J
R823 RD-4Z332J- R CARBON FILM 1/4 3.3K OHM J
R827 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R828 RD-4Z153J- R CARBON FILM 1/4 15K OHM J
R829 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R830 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R831 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R832 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R834 RD-4Z470J- R CARBON FILM 1/4 47 OHM J
R870 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R883 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R884 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RA01 RD-AZ220J- R CARBON FILM 1/6 22 OHM J
RA10 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RA13 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
RA15 RD-AZ680J- R CARBON FILM 1/6 68 OHM J
RA16 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA32 85801060GY WIRE COPPER 1/0.6 TIN COATING
RA35 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA88 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RP03 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RP06 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J
RP08 RD-4Z361J- R CARBON FILM 1/4 360 OHM J
RP10 RD-2Z472J- R CARBON FILM 1/2 4.7K OHM J
RP12 RD-4Z470J- R CARBON FILM 1/4 47 OHM J
RP13 RD-2Z101J- R CARBON FILM 1/2 100 OHM J
ZZ400 PTCPMST2950FS PCB CRT MANUAL AS DTF-2950FZS-SB
C900 CCXB3D102K C CERA 2KV B 1000 PF K (TAPPING)
C910 CEXF2E479V C ELECTRO 250V RSS 4.7MF (10X16)TP
C997 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP
I901 1TDA6108JF IC VIDEO TDA6108JF
I901A 4857025401 HEAT SINK A1050P-H24 T2
I901B 7174300851 SCREW TAPPTITE TT2 RND 3X8 MFZN 3CR
P401A 4859231820 CONN WAFER YW025-05
P501A 4859235120 CONN WAFER YW025-08
P903 4859238620 CONN WAFER YPW500-02
R906 RF02Y629J- R FUSIBLE 2W 6.2 OHM J
SCT1 4859304130 SOCKET CRT ISHG93S
ZZ200 PTCPJRT2950FS PCB CRT RADIAL AS DTF-2950FZS-SB
C902 CMXL2E104K C MYLAR 250V 0.1MF K MEU TP
C921 CMXM2A102J C MYLAR 100V 1000PF J TP
C922 CMXM2A102J C MYLAR 100V 1000PF J TP
C923 CMXM2A102J C MYLAR 100V 1000PF J TP
G900 4SG0DX0001 SPARK GAP SSG-102-A1 (1.0KV)
G901 4SG0DX0001 SPARK GAP SSG-102-A1 (1.0KV)
G902 4SG0DX0001 SPARK GAP SSG-102-A1 (1.0KV)
G903 4SG0DX0001 SPARK GAP SSG-102-A1 (1.0KV)
Q921 TBF423—— TR BF423 TO-92
Q922 TBF423—— TR BF423 TO-92
Q923 TBF423—— TR BF423 TO-92
R905 RN02B102JS R METAL FILM 2W 1K OHM J SMALL
ZZ200 PTCPJAT2950FS PCB CRT AXIAL AS DTF-2950FZS-SB
A001 4859829013 PCB CRT CP-830/830F (DTG/DTH)
D911 D1N4004S— DIODE 1N4004S
D912 D1N4004S— DIODE 1N4004S
D913 D1N4004S— DIODE 1N4004S
D921 D1N4004S— DIODE 1N4004S
D922 D1N4004S— DIODE 1N4004S
D923 D1N4004S— DIODE 1N4004S
D997 DLT2A05G— DIODE LT2A05G
R901 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R902 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
LOC PART CODE PART NAME DESCRIPTION REMARK
R903 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R911 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R912 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R913 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R921 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
R922 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
R923 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
R931 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R932 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R933 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R996 RD-2Z105J- R CARBON FILM 1/2 1M OHM J
R997 RD-2Z102J- R CARBON FILM 1/2 1K OHM J
ZZ140 PTPKCPT2950F PACKING AS DTF-2950FZF-SB
10 6520010200 STAPLE PIN #3417 ALL
M681 2TP06575CL TAPE OPP T0.065XW75X500M CLEAR
M801 DMP5018800 BOX DTL-2950 (NEW)
M811 485819C900DN PAD DOWN 2950 EPS
M811A 485819C900UP PAD UP 2950 EPS
M821 4858215601 BAG P.E. “PE FOAM T0.5X1600X1270 25”-28”
