25
SPECIFICATION
WIRING DIAGRAM
MODEL DWD-WD1353WC/SC/RC,DWD-WD1363WC/SC/RC
Dimension (inches) 27 x 31.8 x 40.1 (W x D x H) (Door open D : 40.9)
Unit Weight (lbm) 198.4(Net) / 227(Gross)
Wash capacity 3.82 cu.ft. DOE
Spin Speed (RPM) 1300 rpm max.
Operating Water Pressure 4.5~145 PSI (30~1000 kPa)
Electrical Spec. 120V / 60Hz, 10 A
