PARTS DIAGRAM
LOC. PART NAME PART CODE SPECIFICATION REMARK
PRPSSW8100 AC 220~230V/50Hz PUMP
5510,5511,6010,6011
PRPSSW8200 AC 220~230V/50Hz N-PUMP
PRPSSW8101 AC 240V/50Hz PUMP
5510,5511,6010,6011
PRPSSW8201 AC 240V/50Hz N-PUMP
PRPSSW8102 AC 220V/60Hz PUMP
5510,5511,6010,6011
PRPSSW8202 AC 220V/60Hz N-PUMP
PRPSSW8103 AC 110V/60Hz PUMP
5510,5511,6010,6011
PRPSSW8203 AC 110V/60Hz N-PUMP
PRPSSW8104 AC 127V/60Hz PUMP
5510,5511,6010,6011
PRPSSW8204 AC 127V/60Hz N-PUMP
A18 PCB AS PRPSSW8205 AC 100V/50,60Hz 5510,5511,6010,6011
PRPSSW8300 AC 220~230V/50Hz PUMP
5520,5521,6020,6021
PRPSSW8400 AC 220~230V/50Hz N-PUMP
PRPSSW8301 AC 240V/50Hz PUMP
5520,5521,6020,6021
PRPSSW8401 AC 240V/50Hz N-PUMP
PRPSSW8302 AC 220V/60Hz PUMP
5520,5521,6020,6021
PRPSSW8402 AC 220V/60Hz N-PUMP
PRPSSW8303 AC 110V/60Hz PUMP
5520,5521,6020,6021
PRPSSW8403 AC 110V/60Hz N-PUMP
PRPSSW8304AC 127V/60Hz PUMP (MEX)
5520,5521,6020,6021
PRPSSW8404 AC 127V/60Hz N-PUMP
PRPSSW8405 AC 100V/50,60Hz 5520,5521,6020,6021
A19 ASSY BUBBLE
3618946300 AC 220~240V/50,60Hz
3618918800 AC 110~127V/50,60Hz (MEX)
3611304600 LFC-3R 3X0.75 2.3M GY
AUSTRALIA, ARGENTINA
3611304700 F H05W 3X0.75 2.3M WH CHILE
3611304800 RW-300/500 3X0.75 2.3M PR. CHINA
3611304900 - VCTF 3X0.75 2.3M INDIA
3611305000 R VCTFK 2X1.25 2.3M GY JAPAN
3611305100 U VCTF 3X0.75 2.3M GY KOREA
A20 CORD POWER AS 3611305200 P VCTF 3X0.75 2.3M GY KUWAIT
3611305300 - VCTF 3X0.75 2.3M WH MALAYSIA
3611305400 - H05W-F 3X0.75 2.3M BK SINGAPORE
3611305500A - VCTFK 2X0.75 2.3M GYMEXICO
3611305600 F H05W 3X0.75 2.3M BK USSR, HUNGARY
3611305700 C SJT 3X18AWG 2.2M GY PANAMA, USA
3611305800 H05W-F 3X0.75 2.3M GY SOUTH AFRICA
3611305900 P VCTF 3.0.75 2.3M WH OMAN
3612754500 NON OPTION
3612754510 NON-BUBBLE PUMP
PUMP
3612754520 NON-HOT INLET VALVE
A21HARNESS ASSY3612754531 FULL OPTION (MEX)
3612754600 NON OPTION
3612754610 NON-BUBBLE PUMP
N-PUMP
3612754620 NON-HOT INLET VALVE
3612754630 FULL OPTION
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
To Next Page
