PARTS DIAGRAM
Parts List
LOC. PART NAME PART CODE SPECIFICATION REMARK
A01 PANEL B
3614219200 ABS 5510,5511,6010,6011
3614220200 ABS (MEX) 5520,5521,6020,6021
3615403830 AC 220~240V/50Hz 5510,5511,6010,6011
3615403810 (NP, N, MP, M) 5520,5521,6020,6021
A02 VALVE INLET(HOT)
3615402130 AC 220V~60Hz 5510,5511,6010,6011
3615402110 (LP, L) 5520,5521,6020,6021
3615403630 AC 110~127V/60Hz (MEX) 5510,5511,6010,6011
3615403610 (TP, T, SP, S) 5520,5521,6020,6021
3615403710 AC 220~240V/50Hz 5510,5511,6010,6011
3615403730 (NP, N, MP, M) 5520,5521,6020,6021
3615402010 AC 220V60Hz 5510,5511,6010,6011
A03 VALVE INLET(COLD)
3615402030 (LP, L) 5520,5521,6020,6021
3615403510 AC 110~127V/60Hz 5510,5511,6010,6011
3615403530 (TP, T, SP, S) (MEX) 5520,5521,6020,6021
3615403310 AC 110V/50, 60Hz 5510,5511,6010,6011
3615403330 (J) 5520,5521,6020,6021
A04 SWITCH SAFETY AS
3619006360 DC 15V 10A 5510,5511,6010,6011
3619043600 (MEX) 5520,5521,6020,6021
A05 PLATE T
3614515000 ABS (MEX) 5510,5511,6010,6011
3614515100 ABS 5520,5521,6020,6021
A06 NOZZLE DETERGENT
3618102000 PP 5510,5511,6010,6011
3618102100 PP 5520,5521,6020,6021
A07 CASE DETERGENT
3611116500 ABS 5510,5511,6010,6011
3611117200 ABS 5520,5521,6020,6021
A08 CAP REAR 3610902600 CR
A09 HANDLE DOOR
3612603600 ABS 5510,5511,6010,6011
3612604000 ABS 5520,5521,6020,6021
A10 DOOR SPRING
3615107700 SUS304 5510,5511,6010,6011
3615108900 SUS304 5520,5521,6020,6021
A11 DOOR B
3611718400 ABS 5510,5511,6010,6011
3611793300 ABS 5520,5521,6020,6021
A12 DOOR F
3611718300 ABS 5510,5511,6010,6011
3611793200 ABS 5520,5521,6020,6021
A13 WINDOW DISPLAY
3615501700 ABS 5510,5511,6010,6011
3615501800 ABS 5520,5521,6020,6021
A14 BRACKET 3610602900 PP
3618911700 9.4µF, CAN TYPE AC 220~230V/50HZ
A15 UNIT CAPACITOR AS
3618911600 8.4µF, CAN TYPE AC 240V/50Hz, AC 220V/60Hz
3618912000 33.6µF, CAN TYPE (MEX) AC 110V/60Hz DWF-650
3618911900 30µF, CAN TYPE (MEX) AC 127V/60Hz DWF-6521P
A16 SENSER PRESSURE 3614201300 DC 5V CDN-D7
A17 PANEL F
3614219100 ABS 5510,5511,6010,6011
3614200100 ABS 5520,5521,6020,6021
✔ Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
