PARTS DIAGRAM
Parts List
LOC. PART NAME PART CODE SPECIFICATION REMARK
B01 COVER UNDER 3611402700 PP
B02 PLATE UPPER 3614514900 PP
B03 COVER B 3611414010 372x508x0.4t, SGCC
B04 HOLDER SUPPORT 3613010300 FRPP, B
B05 HOLDER SUPPORT 3613010200 FRPP, FL
B06 HOLDER SUPPORT 3613010100 FRPP, FR
B07 HANDLE CABINET 3612603300 PP
B08 CABINET 3610808100 1740.2x767.4x0.6t
B09 SARNESS OUTER 3610068700 50/0.18 GREEN ST710480-2 EARTH
B10 BASE U
3610311000 PP 5510, 5520, 6010, 6020
3610311900 PP 5511, 5521, 6011, 6021
B11 FOOT 4509D10020 BUTYL RUBBER
B12 LEG ADJUST AS 3617702200 DWF-5591DPN
B13
HOSE DRAIN O 4505D6700C PE-LD PUMP
HOSE DRAIN O AS 3613213500 EVA L=950 N-PUMP
B14 GUIDE DRAIN HOSE 3612502300 PP PUMP
B15
CLAMP HOSE O 3611202200 HSW-3 PUMP
CLAMP 3611201000 HSW-3, MFZN D36 N-PUMP
B16 COVER PUMP 3611405320 PP PUMP
3963514000 AC 220~240V/50Hz
B17
UNIT DRAIN 3963514010 AC 220V/60Hz
PUMP
PUMP 3963514020 AC 110V/60Hz
3618957410 AC 127V/60Hz
B18 FILTER AS 3611901530 DWF-5590DPNF, E-TYPE PUMP
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
