PARTS DIAGRAM
Parts List
LOC. PART NAME PART CODE SPECIFICATION REMARK
C01 BALANCER AS
4SOSE3000- DWF-650 5510,5511,5520,5521
3616104700 DWF-6010PN 6010,6011,6020,6021
C02 SPECIAL SCREW 4505E05050 5.2x18
C03 TUB I
3618808100 PP 5510,5511,5520,5521
3618808500 SUS 6010,6011,6020,6021
C04 TUB U 3618808601 PP 6010,6011,6020,6021
C05 FILTER AS 4505E82002 PE(90*120) INSERT
C06 GUIDE FILTER
3612503900 PP 5510,5511,5520,5521
3612506700 PP 6010,6011,6020,6021
C07 PULSATOR AS
3619704200 DWF-5510PN 5510,5511,5520,5521
3619704600 DWF-650 6010,6011,6020,6021
C08 SC. PULSATOR FIX AS 4505E3203A 6x26.5, O-RING+SILICON
C09 CAP PULSATOR 3610909300 PP
C10 SPECIAL NUT 4507D83080 SUS 304
C11 SPECIAL WASHER 3616006500 SUS 304
C12 FLANGE TUB 3617201200 ADC-10
C13 SPECIAL SCREW 4505E05040 5x24
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
To Next Page
