PARTS DIAGRAM
Parts List
LOC. PART NAME PART CODE SPECIFICATION REMARK
D01 COVER TUB O 3611414600 PP
D02 TUB O 3618807600 PP
D03 SUSPENSION AS F 3619801700 DWF-5510NP
D04 SUSPENSION AS B 3619801800 DWF-5510NP
D05 NOZZLE BODY 3618101400 PP
D06 HOSE DRAIN I 3613221701 TPE PUMP
D07 HOSE OVERFLOW 3613220700 L=245 N-PUMP
D08 VALVE DRAIN AS 3615404020 5591D, VE N-PUMP
D09 HOSE DRAIN I AS 3613221800 DWF-5510N N-PUMP
D10 BASE 3610302900 SECEN 1.6t
D11 SPECIAL BOLT BASE 4505E83100 6.5x23
D12 HARNESS SUB AS
3612754900 SUB HARNESS+EARTH PUMP
3612754910 SUB HARNESS+EARTH N-PUMP
D13 HOSE 4500D08220 ID=8, L=20 CAVITATION HOSE
D14 CLAMP 4500D08180 SWC BUBB PIE=8
D15 HOSE 4500D08220 ID=8, L=30 BUBBLE HOSE
D16 CLAMP 4500D08180 SWC BUBB PIE=8
D17
HARNESS EARTH INNER
3612757010 L=180 CHILE
3966010270 AC 220~240V/50Hz PUMP
3966010260 AC 220~240V/50Hz N-PUMP
3966320370 AC 220V/60Hz PUMP
D18
SYNCRONOUS MOTOR
3966320360 AC 220V/60Hz N-PUMP
450ED45120
AC 110~127V/60Hz PUMP
450ED45176 AC 110~127V/60Hz N-PUMP
3966130260 AC 100V/50,60Hz N-PUMP
D19 LINK BRAKE 3617801010 PP PUMP
D20 GEAR MECHANISM
3617306000 GM-4900-KJ4XO N-PUMP
3617307310 GM-4900-KJ4PO PUMP
D21 BOLT HEX 7640802011 6B-1 8x20 SW MFZN
D22 PROTECTOR GEAR 3618301300 SBHG 1.6t
D23 BELT V
4507D34020 M 20 50Hz
4507B34020
M19.5 60Hz
D24 SPECIAL WASHER 4505E34030 PP
3964340100 AC 220~240V/50Hz NP, N, MP, M
D25 MOTOR CONDENSER 3964340200 AC 220V/60Hz LP, L
3964340300 AC 110~127V/60Hz TP, T, SP, S
D26 SPECIAL WASHER 4505E34040 PP
D27 BOLT HEX 7650802511 6B-1 8X25 HS MFZN
D28 PULLY MOTOR AS
3618401420 M-TYPE DS=10 DP=53.0 50Hz
3618402800 M-TYPE DS=10 DP=48.5 60Hz
D29 HARNESS SUB AS
3612754900 SUB HARNESS + EARTH + PUMP PUMP
3612754910 SUB HARNESS + EARTH N-PUMP
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
