• GROUND WIRE
In case of 3-wire
power cord, ground
wire will not be
provided
• POWER CORD
• HOSE DRAIN
• LINT FILTER
• COLD WATER TAP
After using the washer,
close the water tap
• DETERGENT CASE
• PULSATOR
• POWER SWITCH
• CONTROL PANEL
• BLEACH INLET
• HOT WATER TAP
After using the washer, close the water tap.
In case of the single valve model,
there is no hot water valve.
• ADJUSTABLE LEG
• SOFTENER INLET
2
PARTS AND FEATURES
ACCESSORIES
DRYTEN (OPTION) COVER UNDER (OPTION) WATER TAP ADAPTER INLET HOSE
HOSE DRAIN (FOR PUMP) HOSE DRAIN CLAMP HOSE DRAIN (FOR NON- PUMP) CONNECTOR INLET(OPTION)
The parts and features of your washer are illustrated on this page.
Become familiar with all parts and features before using your washer.
NOTE
•
The drawings in this book may vary from your washer model.
They are designed to show the different features of all models covered by this book,
Your model may not include all features.
