17
1. They are linked with comp by Fridge set
INPUT CONTROL OBJECT
CONTENTS REMARKS
1. Comp
2. R-Sensor, RT-Sensor
DV Heater
Water Tank Heater
Dispenser Heater
Flap Heater
1. Buzzer sounds if any button of Front-PCB is pushed.
2. Buzzer sounds 3 seconds after initial power input.
3. Buzzer sounds in case of A/S Forced Defrosting and Short (pull down)
Operation or explanation mode.
4. If door is open, buzzer sounds after every 1 minutes for 5 minutes (Door open alarm)
INPUT CONTROL OBJECT
CONTENTS REMARKS
1. Control Front-PCB buttons
2. Door Switch
3. Initial Power Input
Buzzer
4-6. DV Heater, Water Tank Heater, Dispenser Heater and Flap Heater Control
4-8. Buzzer or Alarm Control
1. It is linked with comp when RT-S is less than 59 ℉
2. It is On of HTR Defrosting Mode
3. It is On of Quick ice Mode
INPUT CONTROL OBJECT
CONTENTS REMARKS
1. RT-Sensor
Water PIPE Heater
4-7. Water PIPE Heater Control
Fridge set 35℉ 37℉ 39℉ 41℉ 43℉ 45℉ 47℉
DV Heater
Working
Rate
(on/off)
20/20 19/21 18/22 17/23 13/27 10/30 8/32
Water Tank Heater 17/23 16/24 14/26 12/28 9/31 5/35 0/40
Dispenser Heater
25(20)
/15(20)
18(24)
/22(16)
16(22)
/24(18)
14(20)
/26(20)
11(17)
/29(23)
5(12)
/35(28)
0(6)
/40(34)
Flap Heater
Ex) 25(20)/15(20) :
Dispenser Heater On/Off Time is 25min/15min when ice maker room temp is lower than 14℉
Dispenser Heater On/Off Time is 20min/20min when ice maker room temp is higher than 14℉
2. Water Tank Heater is On when RT-S is less than 59℉
3. When Poor Refrigeration is sensed, They are linked with comp about 5hours
