95XF series Removal and installation
CAB HEATING
4-5
4.3 REMOVAL AND INSTALLATION, HEATER CONTROL PANEL
Removing control panel
1. Turn all control knobs fully to the left (0 and
cold respectively).
2. Remove the radio panel.
3. Remove the attachment bolts (1) from the
control panel.
Note:
If the heating unit is removed, remove the
attachment bolts from the control panel and
put the panel to one side. Do not disconnect
the control cables.
4. Remove the control panel from the frame
and turn it until the control cables can be
reached.
5. Remove the clips from the control cables.
6. Remove the control cables.
7. Disconnect all electrical connections.
8. Remove the control panel.
0
1
2
3
4
K1 01 457
1
3
ᓻ 0209
