EXTERNAL CAB COMPONENTS
Removal and installation 95XF series
4-36
4.21 REMOVAL AND INSTALLATION, LOWER GRILLE
Removing the lower grille
1. Open the bottom step and push the rubber
attachment strip back through the opening.
2. Remove the attachment bolts.
3. Close the bottom step and remove the
lower grille by pulling it upwards from the
attachment points.
K100424
K100425
Installing the lower grille
1. Close the bottom step.
2. Install the lower grille. Make sure that the
steps have been folded in and that the grille
is securely fastened against the front by
means of the attachment clips.
3. Fit the attachment bolts.
4. Open the steps and pull the rubber
attachment strips through the gaps in the
steps.
4
ᓻ 200345
