CAB HEATING
Removal and installation 95XF series
4-8
5. Remove the control panel.
6. Remove the attachment screws on the side
of the heater.
7. Remove the radiator by carefully pulling it
out of the heating unit.
Installing heating radiator
1. Place the radiator and carefully slide it into
the heating unit.
2. Fit new O-rings to the pipes and fit them.
K100401
3. Fit the pipe clamp.
4. Fit the lower air duct.
5. Install the control panel.
6. Fit the radio panel.
7. Top up the cooling system.
3
ᓻ 0209
