ZF 6S-850 GEARBOX
4-2
©
200508
Removal and installation
5
ΛΦ45/55 series
3
Installing gearbox assembly
1. Before positioning the gearbox, one gear
should be engaged in order to allow the input
shaft to slide into the clutch plate during
installation. Also, apply a small amount of the
specified grease to the input shaft.
2. Fit the thrust bearing.
3. Use the jack to move the gearbox towards
the engine and fit the attachment bolts
around the gearbox.
4. Install the clutch servo and tighten the
attachment bolts.
5. Fit the exhaust pipe between the engine
brake and the silencer.
6. Fit the drive flange.
7. Fit the shift control.
8. Fit the cable harness and tachometer
connection.
9. Connect the negative clamp of the battery.
10. Inspect the shift control.
11. Check the oil level after the gearbox has
been installed.
12. If a gearbox of a different type is mounted, or
a gearbox with a different reduction, this
should be reported. If the correct data are
present, they can be input into the VIC using
DAVIE XD.
DAF LF Gearboxes and Clutch Service Manual
