200508 3-5
Removal and installation
EATON FS/6309A GEARBOX
ΛΦ45/55 series
3
6
3.4 REMOVAL AND INSTALLATION, GEARBOX FRONT COVER OIL SEAL
Removing gearbox front cover oil seal
1. Remove the gearbox.
2. Remove the attachment bolts from the
gearbox front cover. Remove the gearbox
front cover. Clean the contact surfaces of the
gearbox front cover and the gearbox
housing.
3. Remove the oil seal from the gearbox front
cover.
Installing gearbox front cover oil seal
1. Fit the seal in the gearbox front cover using
special tool (DAF no. 1329354).
2. Apply sealant to the contact surface of the
gearbox front cover. Fit the gearbox front
cover. Tighten the bolts to the specified
torque. See "Technical data".
3. Fit the gearbox.
V301006
DAF LF Gearboxes and Clutch Service Manual
