TECHNICAL DATA
4-2
©
200508
ZF 6S-850 gearbox
0
ΛΦ45/55 series
3
4.2 TIGHTENING TORQUES
The tightening torques stated in this paragraph
are different from the standard tightening torques
stated in the overview of the standard tightening
torques.
The other threaded connections not specified
must therefore be tightened to the torque
mentioned in the overview of standard tightening
torques.
When attachment bolts and nuts are replaced, it
is important that - unless stated otherwise - these
bolts and nuts are of exactly the same length and
property class as those removed.
Gearbox
Drive flange
Gearbox front cover
Selector shaft housing
Plugs
Attachment bolts 60 Nm
Drive flange ∧ 120 mm attachment bolt 120 Nm
Drive flange ∧ 150 mm attachment bolt 140 Nm
Attachment bolts 23 Nm
Selector housing attachment bolts 23 Nm
Shifting arm lock nut 46 Nm
Gearbox control attachment nut 52 Nm
Bleeder 10 Nm
Oil level check/filler plug 50 Nm
Drain plug 50 Nm
