200508 4-3
Removal and installation
ZF 6S-850 GEARBOX
ΛΦ45/55 series
3
5
4.2 REMOVING AND INSTALLING GEARBOX, CE ENGINE
Removing gearbox, CE engine
1. Disconnect the earth lead from the battery
terminal.
2. Remove the attachment bolts of the prop
shaft flange and remove the prop shaft.
3. If present, remove the attachment bolts from
the intermediate bearing.
4. Remove the attachment bolt from the
exhaust bracket on the gearbox.
5. Remove the clamping strip from the exhaust
pipe.
6. Remove the attachment bolt of the rubber
suspension point on the end of the exhaust.
7. Twist the end-pipe of the exhaust loose and
remove it.
8. Remove the attachment bolts from the clutch
cylinder and remove it.
9. Mark all the electrical connectors and
remove them.
10. Remove the compressor pipe bracket.
11. Remove the selector rod from the adjusting
mechanism in such a manner that the
settings are not changed.
12. Support the gearbox and remove the
attachment bolts around it.
13. Manoeuvre the gearbox to the rear until it is
free and then remove it.
DAF LF Gearboxes and Clutch Service Manual
