200508 1-1
General
ALLISON MD 3060 AUTOMATIC GEARBOX
ΛΦ45/55 series
3
8
1. GENERAL
1.1 GENERAL
The Allison transmission is electronically
controlled and has a diagnostics system that can
record any faults in the memory of the ECU
(Electronic Control Unit). The faults can be read
at a later date. The system is operated and the
faults are read via the selector keypad.
This selector has a display and is located
immediately next to the driver's seat. The selector
replaces the gear lever with manually operated
gearboxes.
Type designation:
Example MD3060 P
R
D
MODE
N
V300392
MD Medium Duty
3 Gearbox series
0 Transmission ratios occurring in quick
succession
6 Number of gears possible
0 Modification number
P PTO version
DAF LF Gearboxes and Clutch Service Manual
