EATON FS/6309A GEARBOX
3-2
©
200508
Removal and installation
6
ΛΦ45/55 series
3
Installing gearbox assembly
1. Engage the highest gear in order to align the
keys of the input shaft with the clutch plate.
2. Fit the gearbox onto the engine. If
necessary, rotate the drive flange in order to
align the keys.
3. Fit the gearbox attachment bolts all around
and tighten them to the specified torque. See
"Technical data".
4. Install the selector rod on the adjusting
mechanism. Use new self-locking nuts.
5. Fit the exhaust intermediate pipe.
6. Fit the exhaust end pipe.
7. Install the compressor pipe bracket.
8. Install the electronic connectors on the
gearbox.
9. Fit the clutch cylinder.
10. Fit the air pipes.
11. Install the intermediate bearing of the prop
shaft and tighten the bolts by hand.
12. Fit the prop shaft flange onto the gearbox.
Tighten the attachment bolts to the specified
torque. See "Technical data".
13. Tighten the intermediate bearing attachment
bolts to the specified torque. See "Technical
data".
14. Check the oil level. See "Inspection and
adjustment".
15. Fit the earth lead to the battery terminal.
Note:
If a gearbox of a different type is mounted, or a
gearbox with a different reduction, this should be
reported. If the correct data are present, they can
be input into the VIC using DAVIE XD.
