MECHANICAL GEARBOX CONTROL
2-6
©
200508
Inspection and adjustment
2
ΛΦ45/55 series
3
15. Hand-tighten the lock nuts (3) of the gearbox
lever without moving the control rod.
16. Tighten the lock nuts (3) on the gearbox lever
to the specified torque without moving the
control rod. See "Technical data".
17. Adjust the length of the torque rod in such a
way that it can be positioned in the control
rod without tension. Tighten the attachment
nut (1) to the specified torque. See
"Technical data".
18. Tighten the lock nuts (2) on the torque rod to
the specified torque without moving the
torque rod. See "Technical data".
19. Remove the special tool from the ball joint.
20. Remove the special tool and fit the gaiter.
See "Removal and installation".
21. Fit the switch button. See "Removal and
installation".
21
3
V3 00 575
DAF LF Gearboxes and Clutch Service Manual
