EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
4-16
©
200423
Removal and installation
5
ΞΦ95 series
4.12 REMOVAL AND INSTALLATION, GEARBOX FILTER ELEMENT
To prevent skin injury, avoid
unnecessary contact with the
drained oil.
ZF gearbox with integrated retarder
Removing the gearbox filter element
1. Remove the attachment bolt (1) of the oil
filter.
2. Pull the filter cover with the filter from the
filter housing.
3. Remove the filter (3) from the filter cover (2).
Do not clean the filter. The filter must always
be replaced.
Note:
If the magnetic disk is still attached to the
back of the filter, separate it from the filter
element and fit it on the new filter element.
}
M3052
1
M3053
M3054
2
3
