DAF XF95 - Page 108

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
4-18
©
200423
Removal and installation
5
ΞΦ95 series
4.13 REMOVAL AND INSTALLATION, WHEEL HUB
FTP leading rear axle
Removing the wheel hub
1. Remove the hub cover (1) using special tool
(DAF no. 1329498)
2. Lift the leading rear axle and support it
properly.
3. Remove the split pin (2) and the hub nut (3).
4. Remove the outer wheel bearing (4).
5. Remove the hub (6) with the wheel.
Installing the wheel hub
1. Apply new grease to the hub (6).
2. Install the hub with the wheel.
3. Fit the outer wheel bearing (4).
4. Fit the hub nut (3).
5. Adjust the wheel bearing play, see chapter
"Inspection and adjustment".
6. Fit the split pin (2).
7. Lower the leading rear axle.
8. Fit the hub cover using special tool
(DAF no. 1329498). Tighten the hub cover to
the specified torque, see main group
"Technical data".
9. Adjust the brakes.
1
2
4
5
6
7
8
9
10
3
S7 00 640
