EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
4-6
©
200423
Removal and installation
5
ΞΦ95 series
4.5 REMOVAL AND INSTALLATION, CENTRIFUGAL OIL FILTER ELEMENT
To prevent skin injury, avoid
unnecessary contact with the
drained lubricating oil.
Removing centrifugal oil filter element
1. Remove the noise encapsulation on the
right-hand side.
2. Clean the cap (3) and surrounding area and
unscrew the central bolt (4).
3. Remove the centrifugal oil filter element (2).
Fitting the centrifugal oil filter element
1. Clean the interior of the cap (3) and fit the
centrifugal oil filter element (2).
2. Check the central bolt (4) for damage.
3. Replace the sealing ring (5) and lightly
lubricate the sealing ring with lubricating oil.
4. Fit the cap (3) and tighten the central bolt (4)
to the specified torque. See "Technical data".
5. Start the engine and check for leakage.
6. Check the lubricating oil level.
}
4
3
2
5
1
M200526
