Chapter 12 Directions on Coiling, Taping and Zigzag Embroidery
158 BECS-A88/C88 computerized embroidery machine owner’s manual
20. D42 Rotary Gap of M Axis: 0~10
The M axis of special embroidery head has mill clearance. So without
compensation, the needle will not fall in the right position. Adjust this parameter
value to ensure that the needle falls in the center of tape.
During machine debugging, parameter value should be “0” when needle falls in
the center of tape. If not, repeat the adjustment to realize the best effect.
Parameter operation is same as above.
Generally, this parameter is managed by professional experts before leaving
factory.
21. D44 M Axis Work OFF Angle: 0, 90
In case of normal and sequin embroidery, the M axis stops at the angle of the set
value. When the distance between the normal embroidery head and special
embroidery head is small, this parameter must be set as 90° to avoid bumping.
The following parameters can be set in direction of Machine parameter 5:
22. D47 Slow Down When Coil Emb: Y/N
Press the key
or in the right side of the screen for adjustment, and
then press
to confirm.
12-4
Relative Operations of Special Embroidery
12.4.1
Shift between Lock Stitch Head and Special Head
1. Manual Shift
In the main screen, press the key
to enter into color changing screen.
To Next Page
