Commissioning radar
Figure 6-3
Commissioning Strobe 6.3
Check the cable connection of strobe. Step 1
You can check whether the strobe flashes in the video image (set the shutter speed of
camera as 0–3, and gain as 30). If it flashes, then it is properly connected. If not, check
the cable connection again.
We recommend to doing the commissioning at night.
Properly adjust the angle of strobe. Step 2
Make sure the light spot in the video image at the center of scenario horizontally and 1/2
of the scenario vertically (set the shutter speed of camera as 0–3, and gain as 30). See
Figure 6-4. If not, adjust the angle of the flashing light.
We recommend to doing the commissioning at night.
Pay attention to the vehicle plate when adjusting the strobe. Make sure
the strobe is not overexposed.
