User's Manual
159
Target Filter
Click
to draw areas to filter the target.
You can configure two filtering targets (maximum size and minimum
size). When the target is smaller than the minimum size or larger than
the maximum size, no alarms will be activated. The maximum size
should be larger than the minimum size.
Enable Enable or disable the face detection function.
Period Define a period during which the motion detection is active.
Alarm Out
Click
to display setting interface.
Enable alarm activation function. Select the alarm output port(s) to
which the peripheral alarm devices are connected. When an alarm
event occurs, the system activates the peripheral alarm devices
connected to the selected output port.
Latch
Set a length of time for the Device to delay turning off alarm after the
external alarm is cancelled. The value ranges from 0 seconds to 300
seconds, and the default value is 10 seconds. If you enter 0, there will
be no delay.
Send Email
Select the
check box to enable the system to send an
email notification when an alarm event occurs.
To use this function, make sure the email function is enabled in
Main
Menu > NETWORK > EMAIL
.
Record Channel
Select the channel(s) that you want to record. The selected channel(s)
starts recording after an alarm event occurs.
The recording for intelligence event and auto recording function must
be enabled. For details, see "5.1.4.9 Configuring Recorded Video Storage
Schedule" and "5.9.1 Enabling Record Control."
PTZ
Click
to display the PTZ interface.
Enable PTZ activation function. For each PTZ camera, select the preset
that you want to be called when an alarm event occurs.
Motion Detect can only activate PTZ preset.
Post Record
Set a length of time for the Device to delay turning off recording after
the alarm is cancelled. The value ranges from 10 seconds to 300
seconds, and the default value is 10 seconds.
