1.2 Check Accessories
Before the installation, please check the accessories one by one according to the packing list.
Please make sure all the components listed are includes.
1.3 Open the Device
Please open the box and then take out the speed dome. See Figure 1-1.
Figure 1-1
Note:
There are two types of IR intelligent speed dome which are shown in Figure 1-1, please refer to
the actual object for details.
There is laser light and IR light on the laser speed dome, the laser light is used for light
compensation while the IR light can be used to indicate whether the laser light is on or off, the
laser light is enabled when the IR light is on.
1.4 Dial Switch Setup
1.4.1 Dial Switch Address and Function
The corresponding functions of dial switch for both analog speed dome and HDCVI speed dome
are different, which will be introduced respectively.
1.4.1.1 Analog Speed Dome
