User’s Manual
7
Take off drive bracket
Align the four screw holes on the disk to those on the drive bracket and fix the disk on the
bracket.
Fix disk
Fix other disks on the bracket as needed.
Fix other disks
Fix the two drive brackets.
This is only needed on models with 8 bays.
Fix drive brackets
Put the drive brackets back and fix them in the DVR.
