User’s Manual
83
Contrast
Adjust the image contrast. The bigger the value is, the more obvious the
contrast between the light area and dark area will become. You can
adjust this value when the contrast is not obvious. However, if the value
is too big, the dark area is likely to become darker and the light area over
exposed. If the value is too small, the image is likely to become dim.
The value ranges from 0 to 100. The default value is 50. The
recommended range is between 40 and 60.
Saturation
Adjust the color shades. The bigger the value, the lighter the color will
become. This value does not influence the general image lightness.
The value ranges from 0 to 100. The default value is 50. The
recommended range is between 40 and 60.
Color Mode
In the
list, you can select
,
,
,
,
,
,
,
and
.
The sharpness, hue, brightness, contrast and saturation will adjust
automatically according to the selected color mode.
EQ
Enhance the image effect. Adjust the effect value.
Click , image is adjusted to the optimized effect automatically.
Click , the current effect setting will be locked.
Only HD analog channel supports this function.
Position
Adjust the display position of the image in the channel window. The
value indicates pixel. The default value is 16.
This function is only supported by analog channel.
Custom
You can customize four color modes.
1. Click
.
The
page is displayed.
2. In the
list, select
, for example. Then
configure the settings for sharpness, hue, brightness, contrast
and saturation. If you select
, the configuration will apply to
all four customized color modes.
3. Click
.
4. On the
page, in the
list, you can select the
customized color mode.
