1.3.3 HCVR42XXA-S2/4216AN-S2 Series
Model
Parameters
HCVR4204A-S2
HCVR4208A-S2
HCVR4216A-S2
HCVR4216AN-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P(1-15fps)/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
HDCVI：1～15f/s（The 1
st
channel supports 25/30f/s）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
1024Kbps-4096Kbps，
For 720P:default value is 1Mbps，max value is 4Mbps
For 960H:default value is 1Mbps，max value is 3Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch, BNC port
8-ch, BNC port
16-ch, BNC port
16-ch, BNC port
Network Video
Input
Max 2 IPC connections（8Mbps）
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same video
source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch，RCA port,
1-ch，RCA port
Audio Output
1-ch，RCA port
Bidirectional
Talk Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch
playback
Max 8-ch
playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm input
N/A
Alarm Output
3-ch alarm output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.

Dahua HDCVI Specifications

General

Hard Drive Support	SATA
Operating Temperature	-10°C to +55°C
Recording Resolution	1080P
Max HDD Capacity	Up to 10TB
Network Interface	RJ45
Video Output	HDMI
Compression	H.264
