Dahua HDCVI User Manual

12
Model
Parameters
HCVR4204A-S3
HCVR4208A-S3
HCVR4216A-S3
HCVR4216AN-S3
Playback Mode
Instant playback, normal playback, event playback, mark playback, smart
playback
Record
Playback
Max 4-ch
playback
Max 8-ch
playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm input
N/A
Alarm Output
3-ch alarm output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Other
Power
DC12V
Power
Consumption
（No HDD）
≤7W
≤8W
≤10W
≤10W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
（No HDD）
≤1.5KG
≤1.65KG
≤1.8KG
≤1.8KG
Installation
Mode
Desk installation
1.3.8 HCVR52XXA-S3/5216AN-S3 Series
Model
Parameters
HCVR5204A-S3
HCVR5208A-S3
HCVR5216A-
S3
HCVR5216AN-S
3
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080P@15f/1080N/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps～6144Kbps，
For 720P:default value is 2Mbps，max value is 4Mbps
For 1080P:default value is 2Mbps，max value is 6Mbps
