User Manual of NVR2XXX(-P4-P8) Series NVR
127
Figure 9. 20 Email Testing Attention
9.2.10 Configuring UPnP
Purpose:
Universal Plug and Play (UPnP) can permit the device seamlessly discover the presence of other network
devices on the network and establish functional network services for data sharing, communications, etc. You can
use the UPnP function to enable the fast connection of the device to the WAN via a router without port mapping.
Before you start:
If you want to enable the UPnP function of the device, you must enable the UPnP function of the router to
which your device is connected.
Steps:
1. Enter the Network Settings interface.
Menu > Configuration > Network
2. Select the UPnP tab to enter the UPnP interface.
Figure 9. 21 UPnP Settings Interface
3. Check checkbox to enable UPnP.
4. Click to open the External Port Settings dialog box. Configure the external port No. for server port, http
port and RTSP port respectively.
Notes:
1) You can use the default port No., or change it according to actual requirements.
2) External Port indicates the port No. for port mapping in the router.
3) The value of the port No. should between 1 and 65535 and the value must be different from each other.
