User Manual of NVR2XXX(-P4-P8) Series NVR
70
Under multi-screen live view mode, the recorded files of the top-left channel will be played back.
Note: Pressing numerical buttons will switch playback to the corresponding channels during playback process.
2. Playback management.
The toolbar in the bottom part of Playback interface can be used to control playing progress, as shown in
Figure 6. 3.
Figure 6. 3 All-day Playback Interface
The channel and time selection menu displays by moving the mouse to the right of the playback interface.
Click the channel(s) if you want to switch playback to another channel or execute simultaneous playback of
multiple channels, as shown in Figure 6. 4 .
Figure 6. 4 All-day Playback Interface with Channel List
Figure 6. 5 Toolbar of All-day Playback
