Dahua NVR5416-EI User Manual

Figure 3-7 Loosen screws
Step 2 Remove the cover in the direction of the arrow as shown in the gure below.
Figure 3-8 Remove cover
Step 3 Turn over the device, and align the HDD to the four holes of bottom panel, and then x
the HDD with screws.
Figure 3-9 Align HDD
Step 4 Connect HDD to the device using data cable and power cable.
User's Manual
90
