Dahua NVR5416-EI User Manual

Step 2 Click to congure the NIC card, and then click OK.
Figure 5-218 TCP/IP
Table 5-58 TCP/IP parameters
Parameter
Description
Network Mode
●
Single NIC : The current NIC card works independently. If the current
NIC card is disconnected, the Device becomes oine.
●
Fault Tolerance: Two NIC cards share one IP address. Normally only
one NIC card is working. When this card fails, the other NIC card will
start working automatically to ensure the network connection. The
Device is regarded as oine only when both NIC cards are
disconnected.
●
Load Balance: Two NIC cards share one IP address and work at the
same time to share the network load averagely. When one NIC card
fails, the other card continues to work normally. The Device is regarded
as oine only when both NIC cards are disconnected.
The Device with single Ethernet port does not support this function.
User's Manual
338

Dahua NVR5416-EI Specifications

General

Model	NVR5416-EI
Operating System	Embedded Linux
IP Camera Input	16
Interface	HDMI, VGA
VGA Resolution	1920 × 1080
Multi-screen Display	Yes
Video Compression	H.265, H.264, MJPEG
Audio Compression	G.711, G.726
Network Protocol	HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP
Mobile Phone Access	Yes
Interoperability	ONVIF, CGI
Browser	Chrome
Record Mode	Manual, Schedule, Motion, Alarm
Backup Method	USB, Network
Playback	Yes
Ethernet	1 RJ-45 port (10/100/1000 Mbps)
USB	2x USB 2.0
RS485	1 port, for PTZ control
Power Supply	100-240V AC, 50/60Hz
Operating Conditions	-10 °C to +55 °C
Video Output	HDMI, VGA
Network Interface	1 RJ-45 port (10/100/1000 Mbps)
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
HDMI Resolution	4K (3840x2160)
