Dahua VTH5341G-W - Cable Connections

3
Table 1-2 Rear panel description
No.
Description
1
USB port, used by project personnel.
2
SD card slot.
3
Alarm ports, power cables, RS-485 port, and network ports are under the cover. For
details, see Figure 1-3.
Cable Connections 1.5
Cable connection Figure 1-3
