Dahua XVR5108C-S2 User Manual

148
1.3.79 XVR5104C-4M/XVR5104HS-4M/XVR5104H-4M Series
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~95%
Dimension
1U case, 375mm(W)×280mm(D)×50mm(H)
Weight
（No HDD）
≤1.60KG
≤1.75KG
Installation
Mode
Desk installation
Model
Parameters
XVR5104C-4M
XVR5104HS-4M
XVR5104H-4M
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
2560*1440@15fps/2048*1536@15fps/1080P/720P/960H/D1/CIF/
QCIF
Video Frame
Rate
PAL:1~25f/s;NTSC:1~30f/s
Video Bit Rate
32Kbps～6144 Kbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support. (Sub-stream max supports 960H encode.)
Audio
Encode
Standard
G.711A, G.711U, PCM, AAC (AAC for the first channel only)
Audio
Sampling Rate
8KHz, 16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port (HDCVI/AHD/TVI/CVBS self-adaptive)
Network Video
Input
 Support 0 IP channel by default.
 Max 6 IP channels connections (Add 2 IP channels and
4-channel analog/digital channel switch.).
 Connection bandwidth: 0Mbps-24Mbps.
Video Output
1-ch VGA output,
1-ch HDMI output,
HDMI/VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
External
Audio Input
1-channel RCA port
