Please select a channel from the dropdown list.
Please input pre-record time here. The value ranges from 0 to 30.
Check the box here to enable redundancy function. Please note this
function is null if there is only one HDD.
Check the box here to enable snapshot function.
Check the box here to enable holiday function.
Click the Setup button, you can set record period. See Figure 5- 102.
There are six periods in one day. If you do not check the date at the
bottom of the interface, current setup is for today only.
Please click Save button and then exit.
Click the Setup button, you can set record period. See Figure 5- 102.
There are six periods in one day. If you check Holiday box, current
channel shall record as your holiday setup here.
Copy function allows you to copy one channel setup to another. After
setting in channel, click Copy button, you can go to interface Figure
5- 103. You can see current channel name is grey such as channel 1.
Now you can select the channel you want to paste such as channel
5/6/7. If you want to save current setup of channel 1 to all channels,
you can click the first box “ALL”. Click the OK button to save current
copy setup. Click the OK button in the Encode interface, the copy
function succeeded.
5.10.4.2.2 Schedule snapshot
The schedule snapshot interface is shown as below. See Figure 5- 104.
Figure 5- 104
For detailed operation information, please refer to chapter 5.10.4.2.1.
