Dahua XVR5108C-S2 User Manual

249
The following figure is based on the HCVR5816S-V2 series product.
Figure 2- 80
The HCVR4832S-S2 rear panel is shown as in Figure 2- 81.
Figure 2- 81
Please refer to the following sheet for detailed information.
SN
Icon
Name
Note
1
Power socket
Power socket
2
Power switch
Power on/off button.
3
RS-232
RS-232 debug COM.
It is for general COM debug to
configure IP address or
transfer transparent COM
data.
