Dahua XVR5108C-S2 User Manual

251
SN
Icon
Name
Note
5
AUDIO OUT
Audio output port
Audio output port. It is to
output the analog audio signal
to the devices such as the
sound box.
6
MIC IN
Audio input port
Bidirectional talk input port. It
is to receive the analog audio
signal output from the devices
such as mike phone, pickup.
7
AUDIO IN
Audio input port
It is to receive the analog
audio signal output from the
devices such as mike phone,
pickup.
8
VIDEO IN
Video input port
Connect to analog camera to
input video signal.
9
MIC OUT
Audio output port
Audio output port. It is to
output the analog audio signal
to the devices such as the
sound box.
 Bidirectional talk output.
 Audio output on
1-window video monitor.

Audio output on
1-window video
playback.
10
VIDEO OUT
Video output port
Connect to video output
devices such as TV.
11
Network port
1000M Ethernet port
12
VGA
VGA video output port
VGA video output port.
Output analog video signal. It
can connect to the monitor to
view analog video.
13
HDMI
High Definition Media
Interface
High definition audio and
video signal output port. It
transmits uncompressed high
definition video and
multiple-channel data to the
HDMI port of the display
device.
14
eSATA
eSATA port
External SATA port. It can
connect to the device of the
SATA port. Please jump the
HDD when there is peripheral
