Figure 4- 141

4.9.3.1.4 Diagnosis

Note

This function is for some series only.

System can trigger an alarm when the stripe, noise, color cast, out of focus, over

exposure event occurred. See Figure 4- 142.

Please refer to chapter 4.9.3.1.1 motion detection for detailed information.
