Daikin ARXG35E3V1B User Manual

Specifications SiBE04-809
4 Specifications
1. Specifications
50Hz 220-230-240V
Note:

The data are based on the conditions shown in the table below.
Model
Indoor Units FTXG25EV1BW FTXG25EV1BS
Outdoor Units
RXG25E3V1B RXG25E3V1B
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.5 (1.3~3.0) 3.4 (1.3~4.5) 2.5 (1.3~3.0) 3.4 (1.3~4.5)
Btu/h 8,500 (4,400~10,200) 11,600 (4,400~15,400) 8,500 (4,400~10,200) 11,600 (4,400~15,400)
kcal/h 2,150 (1,120~2,580) 2,920 (1,120~3,870) 2,150 (1,120~2,580) 2,920 (1,120~3,870)
Moisture Removal L/h 1.2 — 1.2 —
Running Current (Rated) A 3.6-3.4-3.3 4.7-4.5-4.3 3.6-3.4-3.3 4.7-4.5-4.3
Power Consumption
Rated (Min.~Max.)
W 620 (300~950) 820 (290~1,420) 620 (300~950) 820 (290~1,420)
Power Factor % 78.3-79.3-78.3 79.3-79.2-79.5 78.3-79.3-78.3 79.3-79.2-79.5
COP
Rated (Min.~Max.)
W/W 4.03 (4.33-3.16) 4.15 (4.48-3.17) 4.03 (4.33-3.16) 4.15 (4.48-3.17)
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge
of Refrigerant
g/m 20 20
Indoor Unit FTXG25EV1BW FTXG25EV1BS
Front Panel Color Mat Crystal White Mat Crystal Silver
Airflow Rate
m³/min
(cfm)
H 7.7 (271) 9.0 (317) 7.7 (271) 9.0 (317)
M 6.1 (215) 7.9 (278) 6.1 (215) 7.9 (278)
L 4.7 (165) 6.7 (236) 4.7 (165) 6.7 (236)
SL 3.8 (134) 5.4 (190) 3.8 (134) 5.4 (190)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13
Power Consumption (Rated) W 30-30-30 30-30-30 30-30-30 30-30-30
Power Factor % 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 275×840×150 275×840×150
Packaged Dimensions (H×W×D) mm 222×894×345 222×894×345
Weight kg 9 9
Gross Weight kg 13 13
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/33/28/25 38/32/25/22 38/33/28/25
Sound Power H dBA 56 56 56 56
Outdoor Unit RXG25E3V1B RXG25E3V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AFXDC 1YC23AFXDC
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 1.00 1.00
Airflow Rate
m³/min
(cfm)
H 31.3 (1,105) 28.1 (992) 31.3 (1,105) 28.1 (992)
SL 22.4 (791) 22.4 (791) 22.4 (791) 22.4 (791)
Fan
Type Propeller Propeller
Motor Output W 50 50
Running Current (Rated) A 3.45-3.26-3.17 4.55-4.36-4.17 3.45-3.26-3.17 4.55-4.36-4.17
Power Consumption (Rated) W 590-590-590 790-790-790 590-590-590 790-790-790
Power Factor % 77.7-78.7-77.5 78.9-78.8-78.9 77.7-78.7-77.5 78.9-78.8-78.9
Starting Current A 4.5 4.5
Dimensions (H×W×D) mm 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 612×906×364 612×906×364
Weight kg 34 34
Gross Weight kg 40 40
Operation
Sound
H/SL dBA 46 / 43 47 / 44 46 / 43 47 / 44
Sound Power H dBA 61 62 61 62
Drawing No. 3D060166 3D060167
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
5m
