Daikin ARXG35E3V1B User Manual

SiBE04-809 Specifications
Specifications 5
50Hz 220-230-240V
Note:

The data are based on the conditions shown in the table below.
Model
Indoor Units FTXG35EV1BW FTXG35EV1BS
Outdoor Units
RXG35E3V1B RXG35E3V1B
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 3.5 (1.4~3.8) 4.2 (1.4~5.0) 3.5 (1.4~3.8) 4.2 (1.4~5.0)
Btu/h 11,900 (4,800~13,000) 14,300 (4,800~17,100) 11,900 (4,800~13,000) 14,300 (4,800~17,100)
kcal/h 3,010 (1,200~3,270) 3,610 (1,200~4,300) 3,010 (1,200~3,270) 3,610 (1,200~4,300)
Moisture Removal L/h 1.9 — 1.9 —
Running Current (Rated) A 5.1-4.9-4.7 5.4-5.2-5.0 5.1-4.9-4.7 5.4-5.2-5.0
Power Consumption
Rated (Min.~Max.)
W 1,060 (300~1,290) 1,130 (310~1,560) 1,060 (300~1,290) 1,130 (310~1,560)
Power Factor % 94.5-94.1-94.0 95.1-94.5-94.2 94.5-94.1-94.0 95.1-94.5-94.2
COP W/W 3.30 (4.67~2.95) 3.72 (4.52~3.21) 3.30 (4.67~2.95) 3.72 (4.52~3.21)
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge
of Refrigerant
g/m 20 20
Indoor Unit FTXG35EV1BW FTXG35EV1BS
Front Panel Color Mat Crystal White Mat Crystal Silver
Airflow Rate
m³/min
(cfm)
H 8.1 (285) 9.6 (338) 8.1 (285) 9.6 (338)
M 6.5 (229) 8.2 (289) 6.5 (229) 8.2 (289)
L 4.9 (173) 6.7 (236) 4.9 (173) 6.7 (236)
SL 4.1 (144) 5.9 (208) 4.1 (144) 5.9 (208)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13
Power Consumption (Rated) W 30-30-30 30-30-30 30-30-30 30-30-30
Power Factor % 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 275×840×150 275×840×150
Packaged Dimensions (H×W×D) mm 222×894×345 222×894×345
Weight kg 9 9
Gross Weight kg 13 13
Operation
Sound
H/M/L/SL dBA 39/33/26/23 39/34/29/26 39/33/26/23 39/34/29/26
Sound Power H dBA 57 57 57 57
Outdoor Unit RXG35E3V1B RXG35E3V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AFXDC 1YC23AFXDC
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 1.00 1.00
Airflow Rate
m³/min
(cfm)
H 31.3 (1,105) 28.1 (992) 31.3 (1,105) 28.1 (992)
SL 22.4 (791) 22.4 (791) 22.4 (791) 22.4 (791)
Fan
Type Propeller Propeller
Motor Output W 50 50
Running Current (Rated) A 4.95-4.76-4.57 5.25-5.06-4.87 4.95-4.76-4.57 5.25-5.06-4.87
Power Consumption (Rated) W 1,030-1,030-1,030 1,100-1,100-1,100 1,030-1,030-1,030 1,100-1,100-1,100
Power Factor % 94.6-94.1-93.9 95.2-94.5-94.1 94.6-94.1-93.9 95.2-94.5-94.1
Starting Current A 5.2 5.2
Dimensions (H×W×D) mm 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 612×906×364 612×906×364
Weight kg 34 34
Gross Weight kg 40 40
Operation
Sound
H/SL dBA 47 / 44 48 / 45 47 / 44 48 / 45
Sound Power dBA 62 63 62 63
Drawing No. 3D060168 3D060169
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
5m
