Specifications SiBE04-809
6 Specifications
50Hz 220-230-240V
Note:

The data are based on the conditions shown in the table below.
Model
Indoor Units ATXG25EV1B ATXG35EV1B
Outdoor Units
ARXG25E3V1B ARXG35E3V1B
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.5 (1.3~3.0) 3.4 (1.3~4.5) 3.5 (1.4~3.8) 4.2 (1.4~5.0)
Btu/h 8,500 (4,400~10,200) 11,600 (4,400~15,400) 11,900 (4,800~13,000) 14,300 (4,800~17,100)
kcal/h 2,150 (1,120~2,580) 2,920 (1,120~3,870) 3,010 (1,200~3,270) 3,610 (1,200~4,300)
Moisture Removal L/h 1.2 — 1.9 —
Running Current (Rated) A 3.6-3.4-3.3 4.7-4.5-4.3 5.1-4.9-4.7 5.4-5.2-5.0
Power Consumption
Rated (Min.~Max.)
W 620 (300~950) 820 (290~1,420) 1,060 (300~1,290) 1,130 (310~1,560)
Power Factor % 78.3-79.3-78.3 79.3-79.2-79.5 94.5-94.1-94.0 95.1-94.5-94.2
COP
Rated (Min.~Max.)
W/W 4.03 (4.33-3.16) 4.15 (4.48-3.17) 3.30 (4.67~2.95) 3.72 (4.52~3.21)
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge
of Refrigerant
g/m 20 20
Indoor Unit ATXG25EV1B ATXG35EV1B
Front Panel Color Mat Crystal White Mat Crystal White
Airflow Rate
m³/min
(cfm)
H 7.7 (271) 9.0 (317) 8.1 (285) 9.6 (338)
M 6.1 (215) 7.9 (278) 6.5 (229) 8.2 (289)
L 4.7 (165) 6.7 (236) 4.9 (173) 6.7 (236)
SL 3.8 (134) 5.4 (190) 4.1 (144) 5.9 (208)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13
Power Consumption (Rated) W 30-30-30 30-30-30 30-30-30 30-30-30
Power Factor % 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 275×840×150 275×840×150
Packaged Dimensions (H×W×D) mm 222×894×345 222×894×345
Weight kg 9 9
Gross Weight kg 13 13
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/33/28/25 39/33/26/23 39/34/29/26
Sound Power H dBA 56 56 57 57
Outdoor Unit ARXG25E3V1B ARXG35E3V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AFXDC 1YC23AFXDC
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 1.00 1.00
Airflow Rate
m³/min
(cfm)
H 31.3 (1,105) 28.1 (992) 31.3 (1,105) 28.1 (992)
SL 22.4 (791) 22.4 (791) 22.4 (791) 22.4 (791)
Fan
Type Propeller Propeller
Motor Output W 50 50
Running Current (Rated) A 3.45-3.26-3.17 4.55-4.36-4.17 4.95-4.76-4.57 5.25-5.06-4.87
Power Consumption (Rated) W 590-590-590 790-790-790 1,030-1,030-1,030 1,100-1,100-1,100
Power Factor % 77.7-78.7-77.5 78.9-78.8-78.9 94.6-94.1-93.9 95.2-94.5-94.1
Starting Current A 4.5 5.2
Dimensions (H×W×D) mm 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 612×906×364 612×906×364
Weight kg 34 34
Gross Weight kg 40 40
Operation
Sound
H/SL dBA 46 / 43 47 / 44 47 / 44 48 / 45
Sound Power H dBA 61 62 62 63
Drawing No. 3D060170 3D060171
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
5m
