Daikin DAX Series - Product Identification and Description; Model Series and Cooling Capacity; Unit Inspection and Verification; Product Overview and Compatibility

3

DAX
Model Series
DAX
Nominal Cooling Capacity


Product Description

󰀩









DAX0904 DAX1204
Net Weight (Lbs.) 400 400
Shipping Weight (Lbs.) 430 430
Refrigerant R-410A R-410A
Blower Wheel (Dia x Width) 11x10 11x10
Blower Wheel Quan�ty 2 2
Motor Type Direct Drive Direct Drive
Motor Qty 2 2
Motor (HP) 1 1
Motor (RPM) 1200 1200
Evaporator Coil Material
Face Area (Ft²)
10.0 10.0
Number of Rows 4 4
Suc�on Line Quan�ty 2 2
Suc�on Line Connec�on (in)* 1 1/8 1 1/8
Liquid Line Quan�ty 2 2
Liquid Line Connec�on (in)* 3/8 3/8
Metering Device
TXV Type
TXV Quan�ty 2 2
Thermal Expansion Valve
Adjustable (factory installed)
Copper Tubes /AI Fins
*NOTE

Unit Inspection













Codes & Regulations











󰀩
Replacement Parts














NOTE: Installation

