Daikin DAX Series User Manual

5




ONLY

AHKD MODEL
NUMBER
NOMINAL
KW
ELECTRICAL
CHARACTERISTICS
STAGES
 15  1
 15  1
 20  2
 20  2
 30  2
 30  2



KW Correction Factors (-3A Models)
Supply Voltage  230 220 210 
Correction Factor 1    
KW Correction Factors (-4A Models)
Supply Voltage     
Correction Factor 1    
The heating mode temperatures rise is dependent upon




KW CFM 208 240 480
15 2800 12 16 16
15 2900 12 16 16
15 3000 11 15 15
15 3100 11 15 15
15 3200 10 14 14
20 2800 16 22 22
20 2900 16 21 21
20 3000 16 21 21
20 3100 16 20 20
20 3200 15 20 20
30 2800 24 32 32
30 2900 23 31 31
30 3000 23 30 30
30 3100 21 29 29
30 3200 21 29 29
DAX0904 Temperature Rise Table (°F) - 7.5Ton

KW CFM 208 240 480
15 3800 9 12 12
15 3900 9 12 12
15 4000 9 12 12
15 4100 9 12 12
15 4200 8 11 11
20 3800 12 17 17
20 3900 12 16 16
20 4000 12 16 16
20 4100 12 15 15
20 4200 11 15 15
30 3800 19 25 25
30 3900 18 24 24
30 4000 18 24 24
30 4100 17 23 23
30 4200 17 23 23
DAX1204 Temperature Rise Table (°F) - 10Ton



Electrical Supply Wire and MOP
CAUTION
FIRE HAZARD!


WARNING
HIGH VOLTAGE




HIGH VOLTAGE!












WARNING
