Daikin DRC036 - Page 25

25




 
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN WC
SCFM RPM BHP
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN WC
SCFM RPM BHP

0.2 876 539 0.04

0.2 903 556 0.04
0.4 - - 0.00 0.4 - - 0.00
0.6 - - 0.00 0.6 - - 0.00
0.8 - - 0.00 0.8 - - 0.00
1.0 - - 0.00 1.0 - - 0.00

0.2 1494 754 0.36

0.2 1540 778 0.37
0.4 1429 801 0.38 0.4 1473 826 0.39
0.6 1347 855 0.41 0.6 1389 882 0.42
0.8 1235 920 0.44 0.8 1274 948 0.45
1.0 1096 988 0.47 1.0 1130 1019 0.48

0.2 1121 620 0.18

0.2 1156 639 0.18
0.4 1013 690 0.20 0.4 1044 711 0.20
0.6 854 776 0.22 0.6 880 800 0.23
0.8 727 846 0.24 0.8 749 872 0.25
1.0 616 910 0.26 1.0 635 938 0.27

0.2 1315 699 0.27

0.2 1356 721 0.27
0.4 1223 755 0.29 0.4 1261 778 0.30
0.6 1106 826 0.31 0.6 1140 852 0.32
0.8 972 898 0.34 0.8 1002 926 0.35
1.0 861 961 0.37 1.0 888 991 0.38

0.2 1599 788 0.42

0.2 1649 812 0.44
0.4 1529 831 0.45 0.4 1577 857 0.46
0.6 1460 878 0.47 0.6 1505 905 0.48
0.8 1357 940 0.50 0.8 1399 970 0.52
1.0
1238 1004 0.54
1.0
1277 1035 0.55
Shaded area indicates air ow below 900 SCFM (300 SCFM/ton) that
is not recommended for High Stage cooling or heating



 
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN WC
SCFM RPM BHP
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN WC
SCFM RPM BHP

0.2 866 507 0.09

0.2 884 539 0.10
0.4 713 603 0.11 0.4 728 641 0.11
0.6 569 679 0.12 0.6 581 722 0.13
0.8 396 743 0.13 0.8 404 790 0.14
1.0 218 780 0.14 1.0 222 830 0.15

0.2 1379 649 0.23

0.2 1407 690 0.25
0.4 1284 712 0.25 0.4 1310 757 0.27
0.6 1169 783 0.28 0.6 1193 832 0.30
0.8 1055 848 0.30 0.8 1077 901 0.32
1.0 949 901 0.32 1.0 968 957 0.34

0.2 1170 597 0.15

0.2 1194 634 0.16
0.4 1083 662 0.17 0.4 1105 703 0.18
0.6 928 742 0.19 0.6 947 788 0.20
0.8 808 805 0.20 0.8 824 855 0.21
1.0 712 865 0.22 1.0 727 920 0.23

0.2 1379 649 0.23

0.2 1407 690 0.25
0.4 1284 712 0.25 0.4 1310 757 0.27
0.6 1169 783 0.28 0.6 1193 832 0.30
0.8 1055 848 0.30 0.8 1077 901 0.32
1.0 949 901 0.32 1.0 968 957 0.34

0.2 1476 675 0.28

0.2 - - -
0.4 1388 744 0.31 0.4 1416 791 0.33
0.6 1322 794 0.33 0.6 1349 844 0.35
0.8 1178 869 0.36 0.8 1202 923 0.38
1.0
1076 923 0.38
1.0
1098 981 0.41
Shaded area indicates air ow below 1200 SCFM (300 SCFM/ton)
that is not recommended for High Stage cooling or heating
