Daikin DRC036 - Page 26

26




 
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN WC
SCFM RPM BHP
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN WC
SCFM RPM BHP

0.2 1025 559 0.13

0.2 1046 595 0.14
0.4 893 650 0.15 0.4 911 691 0.16
0.6 755 735 0.17 0.6 770 782 0.19
0.8 622 820 0.20 0.8 635 872 0.21
1.0 - - - 1.0 - - -

0.2 1699 771 0.46

0.2 1733 819 0.49
0.4 1625 833 0.50 0.4 1659 885 0.53
0.6 1536 879 0.53 0.6 1567 934 0.56
0.8 1437 935 0.56 0.8 1466 993 0.60
1.0 1293 1007 0.60 1.0 1319 1070 0.64

0.2 1607 746 0.36

0.2 1640 793 0.38
0.4 1519 787 0.37 0.4 1550 836 0.40
0.6 1419 859 0.41 0.6 1448 913 0.43
0.8 1259 932 0.44 0.8 1285 990 0.47
1.0 1175 992 0.47 1.0 1199 1054 0.50

0.2 1783 815 0.54

0.2 1819 866 0.58
0.4 1713 870 0.58 0.4 1748 924 0.62
0.6 1642 889 0.59 0.6 1676 945 0.63
0.8 1543 963 0.64 0.8 1574 1023 0.68
1.0 1428 1015 0.68 1.0 1457 1078 0.72

0.2 1846 838 0.64

0.2 1883 890 0.68
0.4 1775 904 0.69 0.4 1812 960 0.73
0.6 1701 922 0.70 0.6 1736 980 0.75
0.8 1630 973 0.74 0.8 1664 1034 0.79
1.0
1513 1028 0.78
1.0
1544 1092 0.83
Shaded area indicates air ow below 1200 SCFM (300 SCFM/ton)
that is not recommended for High Stage cooling or heating



 
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN WC
SCFM RPM BHP
SPEED
TAP
EXTERNAL
STATIC
PRESSURE
(ESP),
IN WC
SCFM RPM BHP

0.2 1025 560 0.12

0.2 1046 595 0.13
0.4 893 650 0.14 0.4 911 691 0.15
0.6 755 736 0.16 0.6 770 782 0.17
0.8 622 821 0.18 0.8 635 872 0.19
1.0 500 874 0.19 1.0 510 929 0.20

0.2 1817 796 0.44

0.2 1854 846 0.46
0.4 1736 824 0.45 0.4 1771 876 0.48
0.6 1677 863 0.47 0.6 1711 917 0.50
0.8 1598 911 0.50 0.8 1631 968 0.53
1.0 1517 964 0.53 1.0 1548 1024 0.56

0.2 1588 732 0.31

0.2 1620 778 0.33
0.4 1510 793 0.34 0.4 1541 843 0.36
0.6 1432 838 0.36 0.6 1462 890 0.38
0.8 1347 894 0.38 0.8 1375 950 0.41
1.0 1197 974 0.42 1.0 1221 1035 0.44

0.2 1817 796 0.44

0.2 1854 846 0.46
0.4 1736 824 0.45 0.4 1771 876 0.48
0.6 1677 863 0.47 0.6 1711 917 0.50
0.8 1598 911 0.50 0.8 1631 968 0.53
1.0 1517 964 0.53 1.0 1548 1024 0.56

0.2 1918 817 0.50

0.2 1957 868 0.53
0.4 1842 839 0.51 0.4 1880 891 0.54
0.6 1769 894 0.54 0.6 1805 950 0.58
0.8 1702 935 0.57 0.8 1737 993 0.60
1.0
1623 983 0.60
1.0
1657 1044 0.63
Shaded area indicates air ow below 1200 SCFM (300 SCFM/ton)
that is not recommended for High Stage cooling or heating
