For heater kit it is important to set the capacity of the electric heater at Set-up menu on thermostat and DIP switch on
indoor unit control board. For more please see indoor unit I/O manual.
*Revision level that may or may not be designated.
NOTE: Airflow selec�on should meet the minimum requirements as men�oned in the air handler installa�on instruc�ons.
+
For match up with a 2 ton outdoor unit: Heater kit application shall not exceed 10 kW.
++
For match up with a 3 ton outdoor unit: Heater kit application shall not exceed 15 kW.
NOTE: For emergency mode heating, set the dipswitch on Control Board. For heating mode, use the thermostat user menu.
Heater Kit
Selec�on DV25PECB14A* DV37PECC14A*+ DV59PECD14A*++ DV61PECD14A* S-9 S-10 S-11 S-12
No heater - - - - OFF OFF OFF OFF
First 3 5 5 5 ON ON ON ON
Second 5 6 6 6 ON ON ON OFF
Third 6 8 8 8 ON ON OFF ON
Fourth 8 10 10 10 ON ON O
FF OFF
Fih 10 15 15 15 ON OFF ON ON
Sixth X 19 20 20 ON OFF ON OFF
Seventh X X X 25 ON OFF OFF ON
VALID SWITCH SETTINGS
3 knaB SD draoB lortnoC roodnI gnitteS hctiwS piDWk retaeH
Condensate Management Kits*
CMK0008 CMK0009 CMK0010 CMK0011
DV25PECB14** DV37PECC14** DV59PECD14** DV61PECD14**
DFK-B DFK-C DFK-D
DV25PECB14** DV37PECC14** DV59PECD14**
DV61PECD14**
MODELS
HKSX03XC
HKSX05XC
HKSX06XC
HKSX08XC
HKSX10XC
HKSC05XC
HKSC08XC
HKSC10XC
HKSC15XA
HKSC15XB
HKSC15XF
HKSC19CA
HKSC19CB
HKSC20DH
HKSC20DB
HKSC20XF
HKSC25DA
HKSC25DB
DV25PECB14A*
X X XXX XXX
DV37PECC14A*
X XXX XXX X X XXX
DV59PECD14A*
X XXX XXX X X X X
DV61PECD14A*
X XXX XXX X X XXX X X
To Next Page
